Specifications
Please note - specifications subject to change without prior notice.
| FRAME | All-New Series 4 Beyond Road E, 6061 Aluminum, One-Piece Hydroformed Downtube & Motor Mount, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle |
| FORK | Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets |
| RIM | Marin Aluminum Double Wall, 25mm Inner, 18mm Tall, Disc Specific, Tubeless Compatible |
| HUB REAR | Forged Aluminum Alloy, 142x12mm, Disc, 32H |
| HUB FRONT | Forged Aluminum Alloy, 100x12mm, Disc, 32H |
| SPOKES | 14g Black Stainless Steel |
| TIRES | Vee Tire Co., G-Sport, 700x44, Tubeless Compatible |
| DERAILLEUR REAR | Shimano GRX RD-RX822, 12-speed, Clutch |
| DERAILLEUR FRONT | - |
| SHIFT LEVER | Shimano GRX STRX610, 12-speed |
| CRANKSET | Forged Alloy, 42T Steel Chainring |
| MOTOR | Bosch SX Sprint, 250W, 55Nm, Class 3 (28mph, 45Km/h) |
| BOTTOM BRACKET | - |
| CHAIN | KMC E12S |
| CASSETTE | Shimano CSM6100, 10-51T |
| BRAKES FRONT | Shimano GRX RX400, Flat-Mount Hydraulic Disc, 160mm Rotor |
| BRAKES REAR | Shimano GRX RX400, Flat-Mount Hydraulic Disc, 160mm Rotor |
| BRAKE LEVERS | Shimano GRX STRX610 |
| HANDLEBAR | Marin Butted Alloy, Compact 16º Flared Drop |
| STEM | Marin 3D Forged Alloy |
| GRIPS | Marin Shock Absorbing Perforated Tape |
| HEADSET | FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2” |
| SEATPOST | Marin Alloy, 27.2 |
| SADDLE | Marin Beyond Road Concept Elite |
| PEDALS | Flats |
| KICKSTAND | Removable kickstand mount |
| LIGHTS | - |
| BATTERY | Bosch Compact Power Tube 400, 400Wh |
| HMI | Bosch MiniRemote, Bluetooth |
| RANGE | 14-85 miles / 22-137km |
| CHARGE TIME | 3.5 Hrs |
| APP | Bosch eBike Flow App |
